GPS Active Antenna with DC 2.5~5 V Input Voltage (LPG008)

GPS Active Antenna with DC 2.5~5 V Input Voltage (LPG008)

  • GPS Active Antenna with DC 2.5~5 V Input Voltage (LPG008)
  • GPS Active Antenna with DC 2.5~5 V Input Voltage (LPG008)
GPS Active Antenna with DC 2.5~5 V Input Voltage (LPG008)
Product Details:
Place of Origin: Guangzhou
Brand Name: LongPraise
Certification: LongPraise
Model Number: LongPraise
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: OPP/paper box
Delivery Time: 3-7working days
Supply Ability: 30000PCS/DAY
Contact Now
Detailed Product Description
Frequency:: 1575.42+/-1MHz Band Width:: CF+/-5MHz
Polarization:: RHCP Gain:: 5dBi
V.S.W.R:: 1.5
High Light:

gps antenna


gps external antenna


Model LPG008
Frequency 1575±5MHz
Polarization RHCP
Gain >3.5dbi
Amplifier gain >37dbi
V.S.S.W.R <1.5
P-1 >10DBI
F0 100mhz
Power Supply 3v/5v DC
Connector SMA/TNC/N/customized
Mount way Screw
Dimension 96×126mm
Working Temperature -45~85 degree
Storage Temperature -50~90 degree
Humidity 100%

GPS Active Antenna with DC 2.5~5 V Input Voltage

Band Width:CF+/-5MHz
Gain: 5dBi
Impedance: 50ohm
Axial Ratio: 3dB
LNA Gain:28+/-2dB
Noise Figure :1.5
Filter Insertion Loss :3dB
Supply Voltage:2.2-5V DC
Current Consumption:18-35mA
Cable: RG58/174/others
Radome Material:ABS
Mounting Method:Magnet/Adhesive
Ingress Protection:IP67
Vibration:10 to 55Hz with 1.5mm amplitude 2hours
ROHS Compliant

GPS Active Antenna with DC 2.5~5 V Input Voltage
