Item

Specifications

Antenna

Center Frequency

1602-1610MHz  1575.42+-3MHz

Band Width

CF+-5MHz

Polarization

RHCP

Gain

5dBi

V.S.W.R

<1.5

Impedance

50ohm

Axial Ratio

3dbi(MAX)

Dimension

56x52x15mm

LNA

Gain

28+-2dB

Noise Figure

<1.5

Filter Insertion Loss

<3dB

Ex-band Attenuation

35dB@CF±50MHz/50dB@CF±100MHz

Supply Voltage

2.2-5V DC

Current Consumption

10-20mA

V.S.W.R

<2.0

Mechanical

Cable

RG174

Connector

SMA/MCX/FAKRA or others

Radome Material

ABS

Mounting Method

Magnet/Adhesive

Environmental

Operating Temperature

- 40-+85 degree

Relative Humidity

Up to 95%

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally  friendly

ROHS Compliant
